Equipment

Select a piece of equipment below to learn more about it.

Machine Shop



Lapping & Grinding



Parts Cleaning/Degreasing

ADF Parts Washer

Inspection


  • Mitutoyo Height Gage
  • Mitutoyo optical comparator

Sheetmetal


  • Haeger Hardware Press (3)
  • Strippit Super 30/40 manual punch
  • 6' Cincinnati Shear

Welding


  • Miller Dynasty 350 TIG Welder
  • Miller Syncrowave 350XL TIG Welder (2)

  • Miller Invision 352 with dual wire feeder
  • Amada Spot Welder

Part Marking


  • Pryor Dot Peen


Equipment Information



DMG TWIN 65

The TWIN 65 is a twin spindle, twin turret lathe with live tooling allowing turning and milling in a single operation. Both machines are equipped with a bar feeder and unloading arm for continuous production.




DMG CTX 510

The CTX 510 is a two axis lathe utilized for heavy boring and turning.

DMG CTX 410 V4

This multi-axis machine has a 19.9 in. swing, with cross travel
X: 9.8in., Vertical travel Y: 1.6 in. and Longitudinal travel Z: 25.0 in.
A bar feed diameter of 2.6 in. and Spindle speeds from 25-5,000 RPM.

DMG/MORI CTX beta 800

This multi-axis machine has a 27.55 in. swing, with cross travel
X: 11.81 in., Vertical travel Y: 2.3 in. and Longitudinal travel Z: 33.46 in.

HAAS TL-1

Working window 16 x 30, manual/automatic/full CNC

Mori Seiki DMU 50 Five-Axis

The DMU 50 features full five axis simultaneous movement for demanding and complicated parts. These mills are equipped with the Blum Laser Tool Setting System and Renishaw Part Probing. Working window of 19.7” x 17.7” x 15.7” 40-taper, 18,000 RPM with a 60 tool magazine.

HuRco VMX42

This multi-axis machine has a working window of

42” x 24” x 24”, 40-taper and Spindle speed is 10,000 RPM.

Haas VF5/40XT

The Hass VF5/40-XT, has a working window of 60” x 26” x 25” with 4th-axis capability, 40-taper and 7,500 rpm

Haas VF-3

Working window of 40” x 20” x 25” with 4th-Axis capabilities, 40-taper and 7,500 RPM.

11-16 Blanchard Grinder

The 11-16 Blanchard with segmented wheel and magnetic chuck.

Lapmaster M/N 20

Two different configurations allow the use of numerous lapping abrasives.

ADF Parts Washer

The ADF parts washer features heated wash, fresh water rinse and hot air drying with timed cycles.

Brown & Sharpe Global Advantage CMM

The Brown & Sharpe Global Advantage CMM features an articulating probe head, scanning probes and the ability to program directly from the customers model file. This machine has a working window of 35.43” x 59.05” x 31.49” with a PC-DMIS CAD system.

Trumpf TC200R

The TRUMPF TC200 CNC punch press is an innovative departure from the old turret style machines. With a fully rotating head and hydraulically clamped tools, these machines are engineered to impress and built to last.

Trumpf Trumabend V170

The TRUMPF V170 is a six axis 13 foot, 170 ton press brake with programmable crowning for precise and consistent bends.

Amada HFB 5020/81 press brake

Our Amada HFB 5020/81 is a 6 ft / 55 ton press brake with eight axis gauging system.

Cobalt-Pro Laser Marking System

The Cobalt-Pro Laser marking system features a fiber laser, rotary axis and software capable of importing customer designs/logos and creating all types of Bar, QR and Data Matrix codes.
